Crestron TSW-1080 10.1 in. Wall Mount Touch Screen
The TSW-1080 is the 10.1 in. wall panel in Crestron's 80 Series. The die-cast body is 1.18 in. deep and surface mounts over a 2 or 3 gang US box, a 2 gang European DIN 49073 box, or a 2 gang UK BS 4662 box, so it reads flat against the wall outside a room. The 1920 x 1200 display runs Smart Graphics and HTML5 projects with native scheduling applications.
The platform is the current generation: 8 GB of LPDDR4 RAM, 40 GB of pSLC storage, gigabit Ethernet with PoE+, and Wi-Fi 6E 2x2 MIMO on 2.4, 5, and 6 GHz. The streaming decoder takes H.265, H.264, and MJPEG up to 3840x2160 at 30 fps over RTSP with AAC stereo, and a built-in microphone and speakers drive Rava SIP intercom. The government version, TSW-1080-GV-B, is listed here as a variant.
| Display | 10.1 in. (257 mm) TFT active matrix color LCD |
|---|---|
| Resolution | 1920 x 1200 pixels, 16:10 |
| Brightness | 350 to 400 nits (cd/m2), 1000:1 contrast |
| Memory | 8 GB LPDDR4 RAM, 40 GB eMMC pSLC storage |
| Network | 1000 Mbps Ethernet with PoE+, Wi-Fi 6E 802.11a/b/g/n/ac/ax 2x2 MIMO |
| Video | H.265, H.264, MJPEG up to 3840x2160 at 30 fps, RTSP |
| Audio | Built-in microphone and speakers, Rava SIP intercom |
| Mounting | Surface mount over 2 or 3 gang US, 2 gang DIN 49073, or 2 gang BS 4662 box |
| Dimensions | 5.96 in. H x 9.68 in. W x 1.18 in. D (151 x 245 x 30 mm) |
