Crestron TSW-880-GV-B 8.1 in. Wall Mount Touch Screen, Government Version
The TSW-880-GV is the government build of the 8.1 in. wall mount touch screen, intended for deployments where a wireless radio or an open microphone is not allowed in the room. It keeps the same 1280 x 800 capacitive display, the same HTML5 interface engine, and the same 40 GB of storage as the standard TSW-880, and it drops the Wi-Fi and Bluetooth transceivers and the built-in microphone. Audio output is through built-in speakers.
Control reaches it over wired Ethernet only, with PoE+ carrying power on the same run. Five virtual buttons sit in the collapsible tool bar, preconfigured for Power, Home, Lights, Up, and Down, and each can be reprogrammed or hidden. It runs the Crestron scheduling app against Exchange, Microsoft 365, Google Calendar, 25Live, or Ad Astra, and decodes H.265 and H.264 streams up to 3840 x 2160 at 30 fps.
| Display | 8.1 in. (204 mm) diagonal TFT active matrix color LCD, 16:10 WXGA |
|---|---|
| Resolution | 1280 x 800 pixels, 350 to 400 nits, 1000:1 contrast |
| Touch Screen | Projected capacitive, 5 point multitouch capable |
| Buttons | (5) Virtual buttons in collapsible tool bar, per button show or hide |
| Memory | 8 GB LPDDR4 RAM, 40 GB eMMC pSLC storage, 1000 MB maximum project size |
| Network | (1) RJ-45, 1000BASE-TX Ethernet with PoE+ powered device port |
| Streaming Video | H.265, H.264, MJPEG up to 3840 x 2160 at 30 fps, RTSP |
| Audio | Built-in speakers |
