Crestron CLXI-2DIM8 8-Channel Dimmer Module, 2 Feeds, 230V
The CLXI-2DIM8 is the international CLX dimmer, two independent four-channel dimmers in one module space on 230 Volts. Each channel is rated 10 Amps or 2,300 Watts for incandescent, magnetic low-voltage, neon and cold cathode, and dimmable 2-wire fluorescent loads, with 13 Amps per group of four and 5,980 Watts across the module when fed from two 16 Amp feeds. Minimum load is 15 Watts.
Air-gap relays are fitted on every channel output, so an individual circuit can be isolated for service without taking the module offline. High-voltage wiring lands on a CLTI or CLTIBN terminal block, sold separately, and the low-voltage control busses between adjacent CLXI modules on the supplied interconnect cable, terminating at a CAEN-BLOCK.
| Type | 8-channel dimmer module, dual feed, 230 Volt |
|---|---|
| Load Types | Incandescent, magnetic low-voltage, neon/cold cathode, dimmable 2-wire fluorescent |
| Load Rating | 10 Amps (2,300 Watts) per channel; 13 Amps (2,990 Watts) per group of four; 26 Amps (5,980 Watts) per module |
| Minimum Load | 15 Watts |
| Power Requirements | 230 Volts AC, 50/60 Hz, single-phase; all feeds must be the same phase or split phase |
| Service Access | Air-gap relay on every channel output |
| Connections | Via a CLTI or CLTIBN DIN rail terminal block, sold separately |
| Module Interconnect | (2) 5-pin 0.156 inch headers, Cresnet and override ports; interconnect jumpers included |
| Communications | Cresnet, via the module interconnect to a PAC2, PAC2M, or CAEN-BLOCK |
