BZBGear BG-8K-HS21AR 2x1 8K HDMI Switcher with RS-232 and Gain Control

The BG-8K-HS21AR switches two 8K sources to one display at up to 8K60 4:2:0 12-bit, 8K30 4:4:4 12-bit and 4K120 4:4:4 12-bit, with HDCP 2.3 and no measurable added latency on either audio or video.

It is the installed-system version of the HS21A: digital and analog audio de-embedding with gain control on the analog output, RS-232 and wideband IR for control, and a built-in HDMI signal generator so an installer can prove the display and the cable before the source arrives.

HDMI Compliance	HDMI 2.1
HDCP Compliance	HDCP 2.3
Video Bandwidth	48Gbps
Video Resolution	Up to 8K60 YCbCr 4:2:0 12bit, 8K30 RGB/YCbCr 4:4:4 12bit or 4K120 RGB/YCbCr 4:4:4 12bit, 1080p240Hz
Input	2x HDMI IN [Type A, 19-pin female]
Output	1x HDMI OUT [Type A, 19-pin female] 1x OPTICAL AUDIO OUT [S/PDIF, female] 1x L/R AUDIO OUT [5pin-3.5mm Phoenix connector]
Audio Formats	HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD Audio de-embedding output: Optical: Up to LPCM/Dolby/DTS 5.1CH Analog: Only LPCM 2CH
Color Depth	8/10/12-bit
