BZBGear BG-8K-HS41AR 4x1 8K HDMI Switcher with RS-232 and Gain Control

The BG-8K-HS41AR handles four 8K sources into one display at up to 8K60 4:2:0 12-bit, 8K30 4:4:4 12-bit and 4K120 4:4:4 12-bit, HDCP 2.3 compliant, with no added latency.

It is built for an installed system rather than a desk: RS-232 and wideband IR for a control processor, digital and analog audio de-embedding with gain trim on the analog output, and a built-in HDMI signal generator for commissioning a room before the sources are in place. Dolby Atmos, DTS-HD Master Audio and DSD pass through.

HDMI Compliance	HDMI 2.1
HDCP Compliance	HDCP 2.3
Video Bandwidth	48Gbps
Video Resolution	Up to 8K60 YCbCr 4:2:0 12bit, 8K30 RGB/YCbCr 4:4:4 12bit or 4K120 RGB/YCbCr 4:4:4 12bit, 1080p240Hz
Input	4x HDMI IN [Type A, 19-pin female]
Output	1x HDMI OUT [Type A, 19-pin female] 1x OPTICAL AUDIO OUT [S/PDIF, female] 1x L/R AUDIO OUT [5pin-3.5mm Phoenix connector]
Audio Formats	HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD Audio de-embedding output: Optical: Up to LPCM/Dolby/DTS 5.1CH Analog: Only LPCM 2CH
Color Depth	8/10/12-bit
