BZBGear BG-8K-42MA 4x2 8K HDMI 2.1 Matrix Switcher
The BG-8K-42MA shares four HDMI sources with two displays, switching each output independently or sending one source to both at the press of a button. Bandwidth is 48 Gbps with HDCP 2.3, covering 8K60 4:2:0 10-bit, 8K30 4:4:4 and 4K120 4:4:4.
Auto downscaling protects the lower-resolution display in a mixed pair, and audio de-embedding sends sound to optical S/PDIF or an analog stereo output. VRR, FVA and ALLM pass through for games consoles, and the metal case measures 200 x 85 x 21 mm.
- Input4 x HDMI IN [Type A, 19-pin female]
- Output2 x HDMI OUT [Type A
- Video ResolutionsUp to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit
- Power2.05W (Max)
- Weight0.91 lbs [411g]
| HDMI Compliance | 2.1 |
|---|---|
| HDCP Compliance | HDCP 2.3 |
| Video Bandwidth | 48Gbps |
| Video Resolutions | Up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit, 1080p240Hz |
| Input | 4 x HDMI IN [Type A, 19-pin female] |
| Output | 2 x HDMI OUT [Type A, 19-pin female] 1 x OPTICAL [S/PDIF] 1 x L/R [3.5mm Stereo Mini-jack] |
| Audio Formats | HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD Auido de-embedding output: Optical: Up to LPCM/Dolby/DTS 5.1 CH Analog: LPCM 2.0 CH |
| Color Depth | 8/10/12-bit |
| Dimensions | 7.9”(W) x 3.3"(D) x 0.83”(H) [200mm (W) x 85mm (D) x 21mm (H)] |
| Weight | 0.91 lbs [411g] |
| Power | 2.05W (Max) |
HDMIThe digital video and audio connector on cameras, monitors and computers. Cable runs are shorter than SDI.
