BZBGear BG-8K-22MA 2x2 8K HDMI 2.1 Matrix Switcher

The BG-8K-22MA routes two HDMI inputs to two outputs independently, at up to 8K60 4:2:0 10-bit, 8K30 4:4:4 and 4K120 4:4:4 on 40 Gbps of bandwidth. Auto downscaling keeps a lower-resolution display working when the source is running above it.

Audio can be pulled out to optical S/PDIF or analog stereo for a soundbar or amplifier, and EDID management copies a connected display's capabilities back to the source so handshakes settle instead of flickering. The case is metal and measures 145 x 68 x 17 mm.

HDMI Compliance	HDMI 2.1
HDCP Compliance	HDCP 2.3
Video Bandwidth	40Gbps
Video Resolutions	Up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit,1080p240Hz
Input	2x HDMI IN [Type A, 19-pin female]
Output	2x HDMI OUT [Type A, 19-pin female] 1x OPTICAL [S/PDIF] 1x L/R [3.5mm Stereo Mini-jack]
Audio Formats	HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD Auido de-embedding output: Optical: LPCM 2/5.1 CH, Dolby Digital 2/5.1 CH, DTS 2/5.1 CH Analog: PCM 2.0
Color Depth	8/10/12-bit
