Biamp Impera Connect-X MP6 Extender

The Biamp Impera Connect-X MP6 is an extender built for central system control. Power handling is rated at PoE (IEEE 802.3at Class 1, 4W).

Network connections are Ethernet Port Speed: 10/100 Mbps; Autosense: Yes; Number of 3rd-party devices supported: 2. Power consumption is Each I/O can draw up to 24DC / 500mA. In the box: Mounting screws and zipties.

PowerPoE (IEEE 802.3at Class 1, 4W)
Network Connection(s)Ethernet Port Speed: 10/100 Mbps; Autosense: Yes; Number of 3rd-party devices supported: 2
Power ConsumptionEach I/O can draw up to 24DC / 500mA
Included AccessoriesIncluded: Mounting screws and zipties
Weight0.24 lb (110 g)
RS-232Number of Ports: 1 (bidirectional); 2 (unidirectional)
Dimensions (H x W x D)0.86 inches (22 mm) x 5 inches (127.2 mm) with flange x 3.8 inches (92.2 mm)
