Ashton Bentley TX2/DX2 Meeting Room AV Pack The complete two-box room system, TX2 table hub and DX2 room hub together with charging and mounting hardware

The TX2/DX2 Meeting Room AV Pack is the full Ashton Bentley two-box system in one order: the TX2 Table Hub that takes USB-C and HDMI at the table, the DX2 Room Hub that sits behind the display and handles switching and room management, and the charging PSUs and mounting hardware both units need. It is the same pairing sold as two standalone products, specified here as a pack for rooms being built out complete rather than upgraded piece by piece.

The two hubs link over a single Cat6a/Cat7 cable carrying 4K 60 Hz 4:4:4 uncompressed video, audio, USB and control, so no separate cable types have to be pulled between the table and the display wall. A video bar connects at the DX2 end and can be driven BYOD-style from a laptop at the table or from the room's own codec.

Part Number (US Power)	100-00040-US
Pack Contents	TX2 Table Hub, DX2 Room Hub, charging PSUs, mounting hardware
Link Between Hubs	Single Cat6a / Cat7 cable, up to 35 m, 16 Gb/s
Maximum Resolution	4K at 60 Hz 4:4:4 8-bit, uncompressed
TX2 Inputs	1 x HDMI, 1 x USB-C, both with signal auto sensing
DX2 Outputs	2 x HDMI, to the display and a secondary screen
Video Bar Support	BYOD or codec-driven, connected at the DX2
Laptop Charging	Optional 100 W USB-C at the TX2, from the included PSU
