The NCITE-813A pairs AMX's 8x1:3 4K60 presentation switching with amplification from across the HARMAN portfolio, Crown, JBL and dbx, in one chassis. Eight inputs, four HDMI, two DXLite and two RGBHV/VGA, scale down to two local HDMI outputs plus a DXLite output carrying a 4K60 4:4:4 signal with visually lossless compression up to 70 meters over category cable, at full HDMI 2.0 and HDCP 2.2 compliance.

Audio runs through independent 10-band parametric EQ, independent input gain, and variable compression across six embedded digital inputs and six analog stereo or two microphone inputs, with microphone-specific 3-band EQ, gating, auto-ducking and limiting. dbx Advanced Feedback Suppression keeps an open mic from ringing the room, and DriveCore amplification with 70V/100V and stereo connectivity is built into the higher configurations of this platform.

Video Inputs	(4) HDMI, (2) DXLite, (2) RGBHV/VGA
Video Outputs	(2) local HDMI + (1) DXLite scaled output
Max Resolution	4K60 4:4:4, HDMI 2.0 and HDCP 2.2
Distance Transport	DXLite up to 70 meters, visually lossless compression
Audio Inputs	(6) embedded digital, (6) analog stereo or (2) microphone
Audio Outputs	(2) independently configurable balanced pre-amp, plus embedded digital output audio
Audio Processing	10-band parametric EQ, input gain, variable compression; mic channels add 3-band EQ, gating, auto-ducking, limiting
Feedback Control	dbx Advanced Feedback Suppression
Amplification	HARMAN Crown DriveCore amplification, 70V/100V and stereo connectivity
