AMX VPX-1401 4x1+1 4K60 Presentation Switcher

The VPX-1401 is the smaller sibling in AMX's scaling presentation switcher line, built for rooms that need fewer inputs than the VPX-1701 but the same simplicity. Three HDMI inputs and one VGA input feed built-in scaling up to 4K60 4:4:4 with HDCP 2.2 compatibility, output as a mirrored HDMI and HDBaseT pair so a local display and a remote one over category cable both get the same signal.

USB 2.0 distributes over the HDBaseT link for a table-mounted camera or speakerphone, and an extracted audio output with volume control can feed powered speakers directly without a separate DSP. Control is from the front panel, contact closure, NetLinx Native, an open API, or web-based configuration.
