VigilLink GeoBox M803ex Three-channel Edge Blending And Projection-mapping Processor

The M803ex is the three-channel member of VigilLink's GeoBox mapping line, combining edge blending with true projection mapping so a 4K/2K input can be warped onto irregular or non-planar surfaces - columns, domes, building facades - rather than just corrected for a flat screen. Each of its three processing modules takes two HDMI, one DisplayPort, and one VGA input and outputs up to 2048x1080/60Hz, letting one chassis drive and align a three-projector array from a single rack position.

A 10-bit engine holds geometry alignment to up to 120x68 warp control points per channel while keeping system latency to a single 33ms frame pair, and independent R/G/B gamma correction on the blend zones keeps color consistent where projector images overlap. Control is available from the front keypad, an IR remote, RS-232, USB, or Ethernet/web page, and multiple M800EX units cascade together for installs that need more than three channels.
