VigilLink GeoBox M801ex Single-channel Edge Blending And Projection-mapping Processor

The M801ex goes beyond flat-screen edge blending into projection mapping, warping a 4K/2K input onto irregular or non-planar surfaces - columns, domes, building facades - using a 120x68-point warp grid rather than the simpler geometry correction on the entry-level GeoBox boxes. It takes two HDMI, one DisplayPort, and one VGA input and outputs up to 2048x1080/60Hz with a loop-out for daisy-chaining to a second unit.

The 10-bit processor holds latency to a single 33ms frame pair despite the added mapping complexity, and geometry adjustment of up to 600 pixels per direction covers most practical mapping corrections without needing to reposition the projector. At 12" x 6.5" x 1.7" and 3.3 lb, it's sized to sit in a small rack near the projector, drawing 8.4W from a 12V/3.3A supply.
