VigilLink GeoBox UD101 Single-channel 8K/4K Edge Blending Processor

The UD101 is VigilLink's higher-end single-channel processor, accepting DisplayPort up to 7680x4320/30Hz alongside three HDMI 2.0b inputs and outputting a single HDMI 2.0 feed at up to 4096x2160/60Hz - a step up in both input resolution and connector count from the M801ex/M811. A 17x9-point geometry grid handles edge blending and alignment, while built-in PIP/POP and multiview let it combine several sources on screen instead of just blending one.

RGB gamma correction is available per-channel for color-matching adjacent projectors, and 16 selectable output modes give an installer flexibility in matching the processor's output to whatever display or projector is downstream. It runs on a 12V 2-5A supply at up to 13.2W, weighs 6.4 lb, and measures 11.9 x 7.5 x 1.6 inches - the largest footprint of VigilLink's single-channel GeoBox line.

Channels	1
Inputs	3x HDMI 2.0b, 1x DisplayPort 1.4
Outputs	1x HDMI 2.0 + 1x HDMI 2.0b loop-out
Max Input Resolution	DP: 7680x4320 @30Hz; HDMI: 7680x2160 @30Hz, 4096x2160 @60Hz
Geometry Alignment	Up to 17x9 control points, RGB gamma correction
Features	PIP/POP, multiview, 16 selectable output modes
Power	DC 12V 2-5A, 13.2W
Dimensions / Weight	11.9 x 7.5 x 1.6 in; 6.4 lb
