Theatrixx xVision HDMI to SDI Reversible Module - XVVRMHDMI2SDI
XVVRMHDMI2SDI is a Theatrixx xVision reversible module: a rack card that slides into the XVVRF8 8-bay frame and can be fitted facing front or rear, so the connectors land on whichever side of the rack you cable from. It gets a laptop, console or camera HDMI output into the SDI chain. Input is 1 x HDMI 1.2 type A with locking system and output is 2 x 3G/HD/SD SDI BNC. Signal handling follows SMPTE 425 M Level A & B, 424 M Level A, 292 M, 259 M.
Power is Reversible redundant power fed by XVVRF8, (8-Bay Rackmount Frame). Draw is 20W. The frame supplies redundant power to every slot, so a module has no wall-wart of its own and no separate mains run to lose.
- Video Input1 x HDMI 1.2 type A with locking system
- Video Output2 x 3G/HD/SD SDI BNC
- 3G Format Support1080p50, 1080p59.94, 1080p60
- Power SupplyReversible redundant power fed by XVVRF8
- Weight710 g (1.56 lbs)
| Video Input | 1 x 1.2 type A with locking system |
|---|---|
| Video Output | 2 x 3G/HD/SD BNC |
| 3G Format Support | 1080p50, 1080p59.94, 1080p60 |
| SMPTE Standards | 425 M Level A & B, 424 M Level A, 292 M, 259 M |
| SDI Audio Sampling | Sample rate of 48kHz and 24 bit |
| SDI Video Sampling | and 4:4:4 |
| SDI Color Space | YUV and RGB |
| Power Supply | Reversible redundant power fed by XVVRF8, (8-Bay Rackmount Frame) |
| Weight | 710 g (1.56 lbs) |
