Theatrixx xVision SDI Audio De-Embedder Reversible Module - XVVRMSDI2AUDIO

XVVRMSDI2AUDIO is a Theatrixx xVision reversible module: a rack card that slides into the XVVRF8 8-bay frame and can be fitted facing front or rear, so the connectors land on whichever side of the rack you cable from. It folds analog or AES audio into the SDI stream. Input is 1 x 3G/HD/SD SDI BNC and output is 1 x HDMI 1.2 type A with locking system. A reclocked and amplified loop-thru on 1 x 3G/HD/SD SDI BNC lets a local monitor tap the same feed. Signal handling follows SMPTE 425 M Level A & B, 424 M Level A, 292 M, 259 M.

Power is Reversible redundant power fed by TXVV-RF8 (8-Bay Rackmount Frame). Draw is 20W. The frame supplies redundant power to every slot, so a module has no wall-wart of its own and no separate mains run to lose.

  • Video Input1 x 3G/HD/SD SDI BNC
  • Video Output1 x HDMI 1.2 type A with locking system
  • 3G Format Support1080p50, 1080p59.94, 1080p60
  • Power20W
  • Weight710 g (1.56 lbs)
Video Input1 x 3G/HD/SD BNC
Video Output1 x 1.2 type A with locking system
Loop-thru1 x 3G/HD/SD SDI BNC
3G Format Support1080p50, 1080p59.94, 1080p60
SMPTE Standards425 M Level A & B, 424 M Level A, 292 M, 259 M
SDI Audio SamplingSample rate of 48 kHz and 24 bit
SDI Video Sampling and 4:4:4
SDI Color SpaceYUV and RGB
Weight710 g (1.56 lbs)
Power20W
