Theatrixx xVision SDI Line Delay Reversible Module - XVVRMSDIDLY

XVVRMSDIDLY is a Theatrixx xVision reversible module: a rack card that slides into the XVVRF8 8-bay frame and can be fitted facing front or rear, so the connectors land on whichever side of the rack you cable from. It realigns a video feed against audio or a second camera path. Input is 1 x 3G-SDI BNC and output is 4 x 3G-SDI BNC (delayed & mirrored). Signal handling follows SMPTE ST425 M Level A & B, ST424 M, ST292 M, ST259 M.

Power is Reversible redundant power fed by XVVRF8, (8-Bay Rackmount Frame). Draw is 20W. The frame supplies redundant power to every slot, so a module has no wall-wart of its own and no separate mains run to lose.
