Panasonic AK-UC4000GSJ 4K Studio Camera

The AK-UC4000 is a 4K studio and system camera built on a large 11.14-megapixel 4.4K MOS sensor. Beyond-4K sampling delivers 2000 TV lines of resolution in both the horizontal and vertical directions, and in High Sense mode the camera reaches F10 sensitivity while holding a signal-to-noise ratio of 62 dB or higher. It accepts standard 2/3-type B4 broadcast lenses and adds chromatic aberration compensation to keep detail clean across the frame.

Two 12G-SDI outputs plus a TICO-over-SDI feed are standard, carrying UHD without the cabling overhead of quad-link 3G. The camera supports HDR with HLG and the BT.2020 wide color range, and its high-speed modes output 2x, 3x, or 4x at 1080p, 1080i, and 720p for compatibility with a range of slow-motion servers. Shockless gain and servo-controlled ND and CC filters give live operators smooth in-shot adjustments.
