Crestron AMP-X750 X-Series Amplifier, 750 W

The AMP-X750 carries the same per-channel ratings as the rest of the upper X-Series, 250 W into 4 or 8 ohms, 500 W into 8 ohms only, or 500 W at 70V or 100V, and raises the shared ceiling to 750 W total across all channels. That is the useful number when a system has more zones than it has simultaneous demand: the budget goes where the programme material is.

Inputs accept balanced or unbalanced analog line-level. Gain is 29 dB at 8 ohms, input sensitivity is +4 dBu balanced or -10 dBV unbalanced, and the protection set covers overcurrent, undervoltage, over temperature, DC offset, and extreme high frequency.

  • Output Power Per Channel250 W (4 or 8 ohms), 500 W (8 ohms only), 500 W (70V/100V)
  • Total Output PowerWill not exceed 750 W simultaneously across all channels
  • Frequency Response20 Hz to 20 kHz, 0.5 dB at 1 W
  • Power consumption170 W, (3 channels driven at 1/8th output power, 4 Ohms)
  • Weight10.4 lb
Input Signal TypesBalanced or unbalanced analog line-level
Output Power Per Channel250 W (4 or 8 ohms), 500 W (8 ohms only), 500 W (70V/100V)
Total Output PowerWill not exceed 750 W simultaneously across all channels
Frequency Response20 Hz to 20 kHz, 0.5 dB at 1 W
High-Pass Filter-3 dB at 80 Hz, -12 dB/octave (70V and 100V operation only)
THD+N0.1% at 1 kHz at -3 dB full rated output power
S/N Ratio103 dBA, 20 Hz to 20 kHz, balanced
Gain29 dB at 8 ohms
Power consumption170 W, (3 channels driven at 1/8th output power, 4 Ohms); 8.8 W, idle; 0.35 W, power saver (115VAC/60 Hz)
Weight10.4 lb (4.7 kg)
