Crestron AMP-X500 X-Series Amplifier, 500 W

The AMP-X500 shares one power budget across its channels instead of dividing it evenly. Each channel is rated at 250 W into 4 or 8 ohms, 500 W into 8 ohms only, or 500 W at 70V or 100V, with total simultaneous output across all channels capped at 500 W. In practice that means a designer can put the power where the room needs it, a pair of large mains and several small fills, without over-buying an amplifier per zone.

Balanced and unbalanced inputs are accepted on the same connector. Protection covers overcurrent, undervoltage, over temperature, DC offset, and extreme high frequency, and a power-saver mode sleeps the amplifier after 25 minutes with no signal, waking in about half a second on a 0.44 mV threshold.

  • Output Power Per Channel250 W (4 or 8 ohms), 500 W (8 ohms only), 500 W (70V/100V)
  • Total Output PowerWill not exceed 500 W simultaneously across all channels
  • Input Sensitivity1.23 Vrms, +4 dBu balanced; 0.316 Vrms, -10 dBV unbalanced
  • Frequency Response20 Hz to 20 kHz, 0.5 dB at 1 W
  • Power consumption115 W, (2 channels driven at 1/8th output power, 4 Ω); 8.8 W
Input Signal TypesBalanced or unbalanced analog line-level
Output Power Per Channel250 W (4 or 8 ohms), 500 W (8 ohms only), 500 W (70V/100V)
Total Output PowerWill not exceed 500 W simultaneously across all channels
Frequency Response20 Hz to 20 kHz, 0.5 dB at 1 W
THD+N0.1% at 1 kHz at -3 dB full rated output power
S/N Ratio103 dBA, 20 Hz to 20 kHz, balanced
Input Sensitivity1.23 Vrms, +4 dBu balanced; 0.316 Vrms, -10 dBV unbalanced
ProtectionOvercurrent, undervoltage, over temperature, DC offset, extreme high frequency
Power consumption115 W, (2 channels driven at 1/8th output power, 4 Ω); 8.8 W, idle; 0.31 W, power saver (115VAC/60 Hz)
Weight9.93 lb (4.5 kg)
