Community ALC-404D 4-Channel 400W Amplified Loudspeaker Controller

The Community ALC-404D is a 4-Channel 400W amplified loudspeaker controller. Frequency response is 20 Hz - 20 kHz +/-0.5 dB, 1 W @ 8 ohms. Community positions it for large venue work.

Channels: Output Channels: 4 Hi-Z or Lo-Z (bridgeable per ch. pair); Input Channels: Analog - 4; Dante - 4. Amplifier: Supported Topologies: Star. Operating power: 60-264 V; (with reduced power below 90 V). Audio: Signal-to-Noise Ratio: 20 Hz- 20 kHz @ 8 ohms >104 dB(A). Certifications: Auto-sensing Fast Ethernet (IEEE 802.3u, 100 Mbit/s). Weight: Unit Weight: 16.2 lbs (7.3 kg); Shipping Weight: 25 lbs (11.3 kg).

Dimensions (H x W x D)1.75 inches (44mm) x 17.4 inches (442mm) x 14.7 inches (373mm)
Frequency Response20 Hz - 20 kHz +/-0.5 dB, 1 W @ 8 ohms
ImpedanceInput Impedance 20 k ohms balanced
Maximum Input20 dBu
ChannelsOutput Channels: 4 Hi-Z or Lo-Z (bridgeable per ch. pair); Input Channels: Analog - 4; Dante - 4
AmplifierSupported Topologies: Star
ConnectionsSignal-to-Noise Ratio: 20 Hz- 20 kHz @ 8 ohms >104 dB(A)
Operating Power60-264 V; (with reduced power below 90 V)
