Community ALC-3202D 2-Channel 3200W Amplified Loudspeaker Controller

The Community ALC-3202D is a 2-Channel 3200W amplified loudspeaker controller. Frequency response is 20 Hz - 20 kHz +/-0.5 dB, 1 W @ 8 ohms. Community positions it for large venue work.

Channels: Output Channels: 2 Hi-Z or Lo-Z (bridgeable per ch. pair); Input Channels: Analog - 2; Dante - 2. Amplifier: Supported Topologies: Star. Operating power: 60-264 V; (with reduced power below 90 V). Audio: Signal-to-Noise Ratio 20 Hz- 20 kHz @ 8 ohms >111 dB(A). Certifications: Auto-sensing Fast Ethernet (IEEE 802.3u, 100 Mbit/s). Weight: Unit Weight: 17.2 lbs (7.8 kg); Shipping Weight: 25 lbs (11.3 kg).

Dimensions (H x W x D)	1.75 inches (44mm) x 17.4 inches (442mm) x 14.7 inches (373mm)
Frequency Response	20 Hz - 20 kHz +/-0.5 dB, 1 W @ 8 ohms
Impedance	Input Impedance 20 k ohms balanced
Maximum Input	20 dBu
Channels	Output Channels: 2 Hi-Z or Lo-Z (bridgeable per ch. pair); Input Channels: Analog - 2; Dante - 2
Amplifier	Supported Topologies: Star
Connections	Signal-to-Noise Ratio 20 Hz- 20 kHz @ 8 ohms >111 dB(A)
Operating Power	60-264 V; (with reduced power below 90 V)
