Chauvet DJ Shocker FX
The Shocker FX does three jobs in a 2-pound bar: a cool white blinder, an RGB wash, and a strobe. What makes it worth programming rather than just flashing is the zoning - twelve independently controllable sections (eight RGB and four white) let you run chases and split-colour looks across the face of a single fixture, and Chauvet builds in effect macros that combine zone control with strobe patterns.
The tri-color array is 280 LEDs at 50W total, the white blinder section is 56 LEDs at 11W, and together they make 1,981 lumens across a 97-degree beam and 139-degree field - wide enough to cover an audience from a low truss. DMX runs at 8, 18, 30 or 43 channels over 3-pin XLR depending on how much zone control you want; master/slave and the optional IRC-6 handle console-free use. It draws 45W, links twelve units on a 120V circuit, and measures 10.2 x 3.25 x 5.1 inches.
| Light Source (color) | 280 LEDs (tri-color), 50W total, 50,000-hour life |
|---|---|
| Light Source (white) | 56 LEDs (cool white), 11W total |
| Zones | 12 controllable sections (8 RGB + 4 white) |
| Lumens / Illuminance | 1,981 lumens; 219 lux @ 2 m |
| Beam / Field Angle | 97° / 139° |
| DMX Channels | 8, 18, 30 or 43; 3-pin XLR |
| Power | 45W, 0.6A @ 120V; power-links 12 units @ 120V |
| Size / Weight | 10.2 x 3.25 x 5.1 in (260 x 82.6 x 129 mm); 2.0 lb (1.0 kg) |
