BZBGear BG-A88M 8x8 Digital Audio Processor
The A88M is the DSP for a conference room or a divisible space: eight balanced microphone or line inputs, eight balanced line outputs, and the processing that makes a room-mic system usable - acoustic echo cancellation, noise suppression, automatic gain control and an auto mixer that opens and closes channels on its own.
Conversion is 24-bit at 48 kHz, phantom power is +48 V, and maximum microphone gain is 40 dB. Eight programmable GPIO pins on a ten-pin Phoenix connector tie it into wall controls or a control system, alongside LAN and RS-232. The chassis is a 440 mm rack box drawing 9 watts.
- Dimensions17" x 9.8" x 1.8" [440mm (W) x 250mm (D) x 45mm (H)]
- Frequency response+/-0.2dB
- Dynamic range>= 100dB
- Phantom power+48 VDC
- Weight7.3lbs [3.3kg]
| Frequency response | +/-0.2dB |
|---|---|
| THD+N | <= 0.01% |
| Signal to noise ratio | >= 90dB |
| Dynamic range | >= 100dB |
| Maximum microphone gain | 40dB |
| Conversion | 24Bit |
| +48 VDC | |
| Inputs | 8 x Balanced MIC/LINE [3-pin phoenix connector] or 4 x Stereo Audio [3-pin phoenix connector] |
| Outputs | 8 x Balanced LINE [3-pin phoenix connector] or 4 x Stereo Audio [3-pin phoenix connector] |
| Control | 1 x LAN [RJ45] 1 x RS-232 [3-pin phoenix connector] 8 x GIPO [10-pin phoenix connector] |
| Dimensions | 17" x 9.8" x 1.8" [440mm (W) x 250mm (D) x 45mm (H)] |
| Weight | 7.3lbs [3.3kg] |
