AJA ROI DVI DVI/HDMI To SDI Mini-Converter

The AJA ROI-DVI is a Mini-Converter that brings a computer's DVI or HDMI output onto professional SDI, with Region of Interest scaling that extracts just the part of the screen you want and drops the menu bars and desktop clutter. Running AJA's free Mini-Config software over USB gives interactive selection of the region and full control over how it scales onto the output resolution using AJA's scaling algorithms.

The DVI-D input handles resolutions up to 1920x1200 at 60 Hz and passes through a DVI loop for a local monitor, while the SDI output delivers HD or SD over BNC. Audio can come from the 3.5mm analog input or from HDMI embedded audio and is embedded into the SDI output for synchronized routing. The unit measures 5.8 by 3.1 by 1.0 inches, runs on 5 to 20 volts DC from the included universal supply, and carries AJA's five year warranty.
