VigilLink GeoLink M811lite Single-channel Warping Processor

The M811lite trades the M811's edge-blending focus for straight image warping - correcting a projected image for a curved or angled screen, rotating it for a portrait display, or cropping it to fit a non-standard aspect ratio - while keeping the same PIP/POP capability for overlaying a second source. It accepts two HDMI 2.0b, one DisplayPort 1.2a, and one VGA input at up to 7680x2160/30Hz, and outputs to any of 15 selectable resolutions up to 2048x1080/60Hz.

The 120x68-point warp grid and 10-bit processing carry over from the rest of the M-series, and a single-frame-pair 33ms latency keeps it responsive with live sources. At 5.5 lb it's the heaviest of the compact M-series boxes, but otherwise shares the same 12V/2A power input and HDMI loop-out for daisy-chaining as its siblings.
