VigilLink UD101lite Single-channel 4K Warping Processor

The UD101lite trades the UD101's edge-blending focus for image warping - curved screens, corner projections, rotated content - while keeping the same input flexibility (three HDMI 2.0b plus DisplayPort 1.4 up to 7680x4320/30Hz) and the quad-split multiviewer for monitoring several sources on one output. It's the warping counterpart to the UD101 the way the M811lite is to the M811: same connector set, different core processing task.

Output tops out at 4096x2160/60Hz across 16 selectable modes, with PIP/POP and frame-lock synchronization carried over from the UD101. At 2.65 lb and 11.93 x 7.48 x 1.57 inches, it's noticeably lighter than the full UD101 while running on the same 12V/2A, 13.2W power budget.

Channels	1
Inputs	3x HDMI 2.0b, 1x DisplayPort 1.4
Outputs	1x HDMI 2.0 + 1x HDMI 2.0b loop-out
Max Input Resolution	DP: 7680x4320 @30Hz; HDMI: 7680x2160 @30Hz, 4096x2160 @60Hz
Features	Warping, quad-split multiviewer, PIP/POP, frame-lock
Output	16 selectable modes, up to 4096x2160 @60Hz
Power	DC 12V 2A, 13.2W
Dimensions / Weight	11.93 x 7.48 x 1.57 in; 2.65 lb
