VigilLink GeoBox G814 4-channel Curved-screen

The G814 is the 4-channel sibling to the G812, built for curved or wraparound screens using four or more projectors instead of two. It takes the same input mix - two HDMI 2.0b, one DisplayPort, one VGA - and drives four HDMI outputs (up to 2048x1080/60Hz) with a pair of loop-out ports, keeping the same 17x9-point geometry grid and 1/4-pixel adjustment steps as the smaller G812 for precise blend and corner correction.

Edge blending covers overlap zones up to 1920 x 1200 pixels per seam, with independent geometry adjustment up to 600 pixels and a separate 1200-pixel corner-wall adjustment range for screens that aren't perfectly flat. Dual power options (AC 100-240V or DC 12V) and embedded HDMI/SPDIF audio outputs round it out for large-venue installs like planetariums, immersive theaters, or corporate command centers.
