FSR IPS Audio Connector Inserts

FSR builds the IPS audio inserts as small modular front panels that clip into any IPS wall plate, under-table enclosure or rack mount opening, so an audio feed can be added to a room plate without commissioning a custom panel. The set here spans consumer and install formats: stereo RCA pairs, 3.5mm mini stereo, dual 1/4 in stereo jacks, a Speakon loudspeaker connector and a two-position mini 3-pin XLR insert.

Termination is what separates most of these part numbers. The A222S and A223S take the same RCA pair to cap screw terminals, unbalanced and balanced respectively, while the A511S lands a 3.5mm mini stereo jack on a balanced cap screw terminal for a hard-wired run back to a DSP or amplifier. Single-height parts occupy one IPS position and double-height parts two. Every insert is stocked in white and black, and the -LB part numbers ship labeled.
