EtherWAN ED20KEXT-2P Industrial Ethernet Extender (Phoenix Contact 2702409)

EtherWAN ED20KEXT-2P Industrial Ethernet Extender carries Ethernet over existing in-house copper pairs well past the 100m limit of a standard switch port, using SHDSL modulation instead of fiber. It reaches up to 20km (12.4 miles) on 2 or 4-wire copper, at up to 15.3 Mbps in 2-wire operation or 30 Mbps in 4-wire operation, with 2 SHDSL ports and 1 LAN port.

It is network-transparent, needs no IP configuration, and auto-detects both cable type and speed, so it drops into an existing point-to-point, line or ring run without reconfiguring the rest of the network. Specifications above are taken from the EtherWAN/Phoenix Contact datasheet for this product.
