Crestron AM-3200-WF AirMedia Presentation System

The AirMedia Receiver 3200 with Wi-Fi (AM-3200-WF) is the Series 3 room system that pairs wireless presentation with wired sources and built-in display control. It mounts behind or beside a wall display, drives it over HDMI at up to 4K, and routes a room camera, speakerphone, or touch panel back to a connected laptop over USB for BYOD video conferencing. A full set of integration interfaces lets it run a self-contained meeting room rather than just mirror a screen.

Compared with the AM-3100-WF, the AM-3200-WF adds an HDMI input for a wired local source, a balanced/unbalanced audio output for room audio, dual LAN ports to separate corporate and guest traffic, and RS-232 and IR ports for automated display control. Its built-in dual-band radio establishes a point-to-point link with AirMedia Connect adaptors and removes the need for the external access point that the base AM-3200 requires. It is powered by PoE+ or an optional 24V power pack.

Video Output	Up to 3840x2160@60Hz (4K60)
HDMI	(1) HDMI Type A input and output; input up to 1920x1080@60Hz
USB	(2) USB Type A host (USB 2.0 + USB 3.0); (1) USB Type B device (USB 3.0)
Audio Output	5-pin 3.5 mm detachable terminal block, balanced/unbalanced stereo line-level
Network	(2) RJ-45 LAN (dual LAN, one PoE+); built-in dual-band 802.11a/b/g/n/ac/ax Wi-Fi
Display Control	RS-232 up to 115.2k baud; IR output
Power	PoE+ (IEEE 802.3at Class 4) or optional 24VDC power pack; 14 W typical
Dimensions	1.26 in. H x 7.40 in. W x 6.93 in. D
Weight	1.9 lb
