Clear-Com FSE-TCVR-50-IP FreeSpeak Edge IP Transceiver Antenna

The FSE-TCVR-50-IP is the active IP antenna that puts FreeSpeak Edge coverage where the crew works. It carries duplex audio from an Eclipse HX matrix through an E-IPA-HX card and supports up to ten FSE-BP50 beltpacks each. With an E-IPA-HX card holding 64 licensed ports, one Eclipse HX system can run 64 Edge beltpacks across 64 transceivers.

Output power is adjustable from 1 to 24dBm across 5170 to 5875 MHz using OFDM, with three 3dB omni antennas on RP-TNC connectors so directional elements can be substituted for a difficult room. The chassis is IP53 rated, calculated MTBF is 300,000 hours, and it runs from a 100 to 240V AC supply delivering 12V at 5A. The mount bracket is separate, so the unit can be trimmed to 3.37 in deep for a tight truss position.
