BZBGear BG-IPGEAR-PRO-R AV over IP Receiver
The IPGEAR-PRO-R is the decoder that sits at the display end of the IPGEAR-PRO system. It joins a multicast group on the network, pulls the stream from an IPGEAR-PRO transmitter and puts it out over HDMI at up to 4K60 4:4:4, with a maximum of two frames of latency. Several receivers can share one source, and a group of them can be arranged into a video wall.
Five USB ports on the receiver take a keyboard, mouse and other peripherals for KVM control of the source machine, and IR and RS-232 pass back to the transmitter end. It is powered over the network cable via PoE and is TAA compliant. This is the receiver only; transmitters and the controller are ordered separately.
| Role | Receiver [RX] |
|---|---|
| Video support | Up to 4K2K@60 (4:4:4 8bits) |
| Latency | 2 frames (33 ms) maximum |
| Transmission distance | Ultra HD (4K2K60) - 120m (396ft) [CAT.X] |
| Audio support | Surround sound (up to 7.1ch) or stereo digital audio |
| Inputs | 1x RJ45 + 1x HDMI + S/PDIF |
| Outputs | 2x 3.5mm + 5x USB |
| IR pass-through | Full-duplex bi-directional |
| Power supply | 5V DC / 48V POE |
| Dimensions (L x W x H) | 7.6" x 5.2" x 1.1" [194 x 133 x 28 mm] |
| Weight | 1.4 lbs [644g] |
