BZBGear BG-IPGEAR-XTREME-F HDMI 2.1 Fiber Extender
The BG-IPGEAR-XTREME-F carries HDMI 2.1 over single-mode fiber for up to 10 km with no frame of added latency. It handles uncompressed 4K60 4:4:4, visually lossless 4K144 4:4:4 and 8K60 4:4:4 with DSC, on the full 48 Gbps FRL 6 link with HDCP 2.3.
Everything a room needs travels on the same fiber: bi-directional IR, full-duplex RS-232, USB 3.1 KVM for remote peripherals, 1 Gb Ethernet pass-through, and eARC or ARC returning Dolby Atmos and DTS:X from the display. Fiber is immune to the electrical interference that limits copper runs, which is why this is the extender for a broadcast plant, a medical imaging suite or a control room. Transmitter and receiver are sold separately.
| HDMI compliance | HDMI 2.1 |
|---|---|
| HDCP compliance | HDCP 2.3 |
| Video bandwidth | 48Gbps (FRL 6) |
| Video resolution | 8K@60Hz 4:4:4 DSC, uncompressed 4K@60Hz 4:4:4, visually lossless 4K@144Hz 4:4:4 |
| Transmission distance | Up to 10km (6.25 miles) over single-mode fiber |
| Latency | Zero frame latency |
| USB | USB 3.1 KVM |
| Also carried | Bi-directional IR, full-duplex RS-232, 1Gb Ethernet, eARC/ARC |
