BZBGear BG-EXH-70UCWP-W HDMI and USB-C Wall Plate HDBaseT Kit with RS-232

The BG-EXH-70UCWP-W is the HDBaseT version of BZBGear's HDMI and USB-C wall plate. The Decora-style plate takes an HDMI input and a USB-C input, switches between them, and sends 4K up to 70 m over Cat6, Cat6a or Cat7 to the included receiver.

Bi-directional RS-232 passes through for up to 40 m of control cable, and the plate can be powered over Ethernet from the receiver so no mains is needed behind the wall. Video runs at 18 Gbps for HDMI and 5.4 Gbps over USB-C, with HDR and the full HDMI audio set carried.

HDMI Compliance	HDMI 2.0b
HDCP Compliance	HDCP 2.2
Video Bandwidth	USB-C: 5.4 Gbps HDMI: 18 Gbps
Video Resolution	480i~1080p50/60Hz, 4Kx2K@24/30Hz, 4K2K@60Hz
Transmission Distance	Max distance (1080P) : 230ft / 70m over CAT6/6a/7 Max distance (4K): 131ft / 40m over CAT6/6a/7
HDMI Audio Formats	LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Color Depth	8/10/12-bit (1080P@60Hz) 8-bit (4K@60Hz)
Color Space	RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
