BZBGear BG-4K-VP88 8x8 Seamless Matrix and Video Wall Processor

The 4K-VP88 is the eight-by-eight version of the seamless processor. Eight HDMI inputs feed eight outputs with no black frame on a switch, and the same chassis builds video walls and multiviewer layouts, which removes two separate boxes from a control room rack.

Video runs at 4K60 YUV 4:4:4 8-bit on an 18 Gbps path with HDCP 2.2 and 1.4 support, and DTS 5.1 and Dolby 5.1 audio pass through. Control is front panel, IR, IP or RS-232. The chassis is 438 mm wide by 416 mm deep and draws up to 92 watts.
