BZBGear BG-3GSH SDI to HDMI Converter

The BG-3GSH puts an SDI camera or router feed onto an HDMI display. It accepts SD-SDI, HD-SDI and 3G-SDI at up to 2.970 Gbit/s and meets SMPTE 425M, 424M, 292M and 259M-C, so it sits happily between broadcast gear and a consumer monitor.

It also converts SMPTE 425M Level B to Level A for 1080p 50/59.94/60 4:2:2 10-bit, which is the piece most cheap converters leave out. The box is palm-sized, runs on 5 to 12V DC, and draws 5W at most.

In/Output Resolution	480i, 576i, 720p@50/59.94,60, 720p@50/59.94,60, 1080i@50/59.94/60, 1080p@23.97/24/25/29.97/30/50/59.94/60
Input Port	1 x BNC (SDI/HD-SDI/3G-SDI)
Output Port	1 x HDMI
SDI Transmission Rates	2.970 Gbit/s and 2.970/1.001 Gbit/s
Power Supply	DC 5V - 12V
Power Consumption (Max)	5W
Dimension	3.1in x 1.6in x 0.98in [80mm x 41mm x 25mm]
Weight	0.33 lbs [150g]
