AKG PCC130 SW Boundary Layer Microphone

The PCC130 SW is a cardioid boundary-layer microphone sized to fit on small conference and meeting tables where AKG's larger PCC160/170 plates would crowd the surface. Low self-noise and high sensitivity let it pick up voices clearly at a distance, and a bass-tilt switch tailors the low end and cuts subsonic rumble.

The SW version adds a silent-operating programmable membrane switch that can be configured for touch on/off, momentary-on, or momentary-off use, with a high-intensity LED to show the unit's state at a glance. It connects over a standard XLR with a detachable cable for straightforward installation.

TypeBoundary-layer (PCC) microphone
Polar PatternCardioid
Frequency Response50 - 20,000 Hz
Sensitivity22 mV/Pa
Equivalent Noise Level22 dB-A
FeaturesBass-tilt switch; silent programmable mute switch; status LED
Powering12 - 48 V phantom
OutputSwitchcraft TB3M XLR, detachable cable
