AKG PCC130 SW Boundary Layer Microphone
The PCC130 SW is a cardioid boundary-layer microphone sized to fit on small conference and meeting tables where AKG's larger PCC160/170 plates would crowd the surface. Low self-noise and high sensitivity let it pick up voices clearly at a distance, and a bass-tilt switch tailors the low end and cuts subsonic rumble.
The SW version adds a silent-operating programmable membrane switch that can be configured for touch on/off, momentary-on, or momentary-off use, with a high-intensity LED to show the unit's state at a glance. It connects over a standard XLR with a detachable cable for straightforward installation.
| Type | Boundary-layer (PCC) microphone |
|---|---|
| Polar Pattern | Cardioid |
| Frequency Response | 50 - 20,000 Hz |
| Sensitivity | 22 mV/Pa |
| Equivalent Noise Level | 22 dB-A |
| Features | Bass-tilt switch; silent programmable mute switch; status LED |
| Powering | 12 - 48 V phantom |
| Output | Switchcraft TB3M XLR, detachable cable |
