AKG PCC170 Boundary Layer Microphone
The PCC170 is a professional boundary-layer microphone with a supercardioid pattern that minimizes background noise and feedback, designed for boardroom tables and lecterns. Its low-profile plate sits flat on the surface for a discreet, wide, and smooth pickup, and built-in RFI suppression keeps it clean even with active cell phones nearby.
A bass-tilt switch tailors the low-end response and reduces subsonic rumble. The PCC170 SW variant adds a silent programmable membrane switch that can be configured for touch on/off, momentary on, or momentary off. Both use an XLR connector with a detachable cable for easy installation.
| Type | Boundary-layer (PCC) microphone |
|---|---|
| Polar Pattern | Supercardioid |
| Frequency Range | 50 - 20,000 Hz |
| Sensitivity | 22 mV/Pa |
| Equivalent Noise Level | 22 dB-A |
| Features | Bass-tilt switch; RFI suppression; SW adds programmable membrane switch |
| Powering | 12 - 48 V phantom |
| Output | XLR (Switchcraft TB3M), detachable cable |
