Tascam LM-8ST 8-Channel Stereo Line Mixer

The LM-8ST mixes eight balanced stereo line sources on 1/4 inch TRS inputs, each with a -10/+4 dB sensitivity switch so consumer and professional sources can share the same rack without an external pad. A separate microphone input with front-panel trim handles announcements or a talkback feed.

Two stereo buses leave on balanced XLR as ST1 and ST2/AUX, and both 1/4 inch and 1/8 inch headphone outputs are provided for local monitoring. A two-segment LED meter per channel gives enough indication to catch a hot source, and the universal 100 to 240 V supply draws 15 W in a 1U, 8.4 lb chassis.
