RCF EVOX J11 Three-Way Portable Column PA System
The EVOX J11 moves up to a three-way design, adding a dedicated 1.75-inch neodymium compression driver above twelve 3-inch full-range transducers for sharper vocal clarity than the two-way J-series boxes. A 12-inch powered subwoofer anchors the low end, and the 3500W peak Class-D amplifier (2000W LF, 1500W HF) reaches 132 dB SPL across 37 Hz to 20 kHz.
Coverage spans 120 by 40 degrees, wide enough for a full room without stacking multiple columns, and Powercon TRUE1 TOP power in/out plus combo XLR/jack inputs make it simple to link cabinets. At 29 kg it stores in one piece and breaks down fast for bands and DJs moving between rooms in a night.
| Configuration | Three-way powered column array + subwoofer |
|---|---|
| Satellite Array | 12 x 3" neodymium full-range |
| Compression Driver | 1.75" neodymium |
| Subwoofer | 12" (2.5" voice coil) |
| Amplifier Power | 3500W peak (2000W LF + 1500W HF) |
| Max SPL | 132 dB @ 1m |
| Frequency Response | 37 - 20,000 Hz |
| Coverage | 120 x 40 degrees |
| Connectors | Combo XLR/jack input, XLR output, Powercon TRUE1 TOP |
| Weight | 29 kg (63.93 lbs) |
