QSC MP-MFC Wall Controller for MP-M Series Mixers

The MP-MFC is a wall-mount controller for QSC's MP-M Series music and paging mixer, giving end users hands-on control of zone source selection, output level, input level, and scene recall without opening an app. Three large buttons (increment, decrement, select) work with a crisp 27 x 26 mm graphic display that clearly labels whatever functions the installer has configured.

Each MP-M Series mixer has two MFC ports, and each port daisy-chains up to four controllers over standard CAT5 (RJ45) cabling with a 250 meter maximum run, for up to eight MP-MFC units total on one mixer. Designers set how much or how little control each unit exposes using the free MP Install app.
