PreSonus HP Headphone Amplifier
Three answers to the headphone problem, scaled to the size of the session. The HP2 is a belt-pack stereo amplifier for a performer on in-ear monitors: two XLR line inputs, a stereo 1/8-inch output with volume, a stereo/mono switch and a pan knob, running from a 9V battery or a DC supply, with a 2 m cable in the box.
The HP4 is a four-output distribution amp with left and right line inputs, line outputs with level control, per-output level, stereo-to-mono summing, and a monitor mute that leaves the headphone outputs live. It takes a third of a rack space or sits on a table. The HP60 is the full cue system: six headphone amps each with its own level, two stereo line inputs routed to all six with a per-channel Mix control so each musician can balance a click against the main mix, plus an external stereo input, mono and mute per channel, a talkback mic input with a Talk button, and a footswitch input. Two HP60s chain for twelve headphones.
| Type | HP2 personal stereo amp / HP4 4-channel distribution / HP60 6-channel mixing system |
|---|---|
| HP2 I/O | 2x XLR line input, 1x stereo 1/8" headphone output with volume |
| HP2 Power | 9V battery or DC power supply; 2 m audio cable included |
| HP4 I/O | L/R line inputs, L/R line outputs with level, 4 headphone outputs |
| HP4 Format | One third of a rack space, tabletop or rack-tray mountable |
| HP60 Inputs | 2x stereo line inputs to all six outputs, plus external stereo input with level |
| HP60 Per Channel | Level, Mix control, mono, mute |
| HP60 Talkback | Talkback mic input with Talk button and footswitch input |
| Expansion | Two HP60s for 12 headphones, or HP60 plus HP4 for 10 |
