Opticis DPFX-700-TR DisplayPort1.2 Optical Extender

The DPFX-700-TR is Opticis's displayPort1.2 Optical Extender. It carries the signal up to 300 m (984 feet) over one (1) LC multi-mode fiber, with no scaling and no compression in the path. Resolution support runs to 4K (4096x2160) at 60Hz.

Supports DisplayPort 1.2 standards. Fully compatible with using DPFX-300 as a pair. Power Rack (BR-400) available for mounting up to 8 units. Offers total data rate 21.6 Gbps.

Standards	Supports DisplayPort 1.2 standards
Resolution	Extends up to 4K (4096x2160) at 60Hz
Transmission Distance	Transmits DisplayPort 1.2 data up to 300m (984 feet) over one (1) LC multi-mode fiber (OM3)
Compatibility	Fully compatible with using DPFX-300 as a pair
Power	Power Rack (BR-400) available for mounting up to 8 units
Bandwidth	Offers total data rate 21.6 Gbps
Isolation	Data security with negligible EMI emission
Part Number	DPFX-700-TR
