MuxLab 500081 Digital Audio Converter, Dolby Digital

The 500081 accepts a Dolby Digital stream on either a coaxial S/PDIF or optical TOSlink input, decodes it, and downmixes it to two-channel analog stereo. It is the right part when the source outputs a compressed bitstream that a plain converter would pass through as noise.

Sample rate runs to 96kHz and the unit handles 24-bit S/PDIF compressed and uncompressed bit streams. Output is a pair of color-coded RCA connectors, and a front switch selects which digital input is active. An optical cable is included.

Standard	Digital Audio, Dolby Digital Digital Audio
Signal Format	Dolby Digital and 2 channel LPCM (Linear Pulse Code Modulation)
Bit Depth	24 bit S/PDIF bitstream on right and left channels
Connectors	One (1) Coaxial connector One (1) TOSLink Connector. Two (2) RCA
Power Supply	One (1) 110-240V/5VDC power supplies with interchangeable blades
Power Consumption	0.75 Watt
Dimensions	2.4" x 2.25" x 1.0" (6.1 x 5.5 x 2.5 cm)
Weight	1.0 lb (0.45 kg)
