Kramer WP-20CT 4K60 4:2:0 HDMI & USB-C Wall-Plate Auto Switcher/Transmitter over Long-Reach HDBaseT

The WP-20CT fits a standard 1-gang wall box and gives a room one USB-C input (DisplayPort Alt Mode) and one HDMI input that auto-switch to a single HDBaseT output, with out-of-the-box Maestro room control handling display power automatically - a CEC-enabled display turns on when a source plugs in and off again after a user-set delay. Any DP-Alt-Mode USB-C laptop connects as an AV source while simultaneously drawing up to 60W of USB Power Delivery charging through the same cable, when paired with Kramer's optional 20V power supply - a genuine one-cable BYOD connection.

HDMI switching is HDCP 2.3 compliant and passes Deep Color, x.v.Color, Dolby TrueHD and DTS-HD at up to 4K@60Hz (4:2:0), and the extension link reaches 40m at 4K or 70m at full HD over Kramer HDBaseT cable. A bidirectional RS-232 port extends serial control to the room end, and the unit accepts PoE from a compatible receiver or matrix, with mains power as a fallback. Local device management runs through a built-in web interface reachable over the USB-C connection, and firmware updates via USB-C or RS-232.
