DVDO CAT4K-70 4K60 HDMI 70m Extender Over Category with ARC (Tx/Rx)
The CAT4K-70 is DVDO's 4K60 HDMI 70m Extender Over Category with ARC (Tx/Rx). HDMI 2.0b and HDCP 2.2 compliant.
Supports video resolutions up to 4K2K@60Hz RGB/YCbCr 4:4:4. Maximum transmission distance: 230ft/70m with CAT6/6a cable. Can copy EDID from the display connected either to the receiver or to the transmitter's loop out. Allows cascading to other HDMI extenders through the HDMI loop out. ARC and audio de-embedding, audio output through the optical port of the receiver.
- HDCPHDMI 2.0b and HDCP 2.2 compliant
- VideoSupports video resolutions up to 4K2K@60Hz RGB/YCbCr 4:4:4
- ReachMaximum transmission distance: 230ft/70m with CAT6/6a cable
- FeatureHDR, HDR10, HDR10+, Dolby Vision, HLG
- ControlBi-directional IR control
| HDCP | 2.0b and HDCP 2.2 compliant |
|---|---|
| Video | Supports video resolutions up to 4K2K@60Hz RGB/YCbCr 4:4:4 |
| Reach | Maximum transmission distance: 230ft/70m with CAT6/6a cable |
| Signal Handling | Can copy EDID from the display connected either to the receiver or to the transmitter's loop out |
| Connectivity | Allows cascading to other HDMI extenders through the HDMI loop out |
| Audio | ARC and audio de-embedding, audio output through the optical port of the receiver |
| Feature | HDR, HDR10, HDR10+, Dolby Vision, HLG |
| Also | Bi-directional PoC (Tx or Rx) |
| Control | Bi-directional IR control |
| Form Factor | Compact design for easy and flexible installation |
| Part Number | DVDO-CAT4K-70 |
HDMIThe digital video and audio connector on cameras, monitors and computers. Cable runs are shorter than SDI.
