DigiTech SDrum
SDRUM is a drum machine you program by playing guitar. Its BeatScratch technology listens to you scratch across the strings and lays out a kick and snare pattern from what it hears, which is a faster way to get a usable groove than tapping a grid. Kick and snare pads on the top panel let you audition kits and tap patterns in by hand as well.
Five kits cover a wide range of genres, and the Groove/Kit knob also sets embellishment level, feel and time signature. Each song holds three parts - think verse, chorus, bridge - each with three intensities, switchable on the fly with the footswitch for live use, and the pedal stores up to 36 songs. Outputs cover an amp out, impedance-balanced stereo mixer outs and a JamSync out for syncing to JamMan loopers. It ships with a PS0913DC 9V supply.
| Effect | Guitar-taught drum machine |
|---|---|
| Programming | BeatScratch - strum across the strings to teach a kick/snare pattern |
| Kits | 5 |
| Song Storage | 36 songs, 3 parts per song, 4 bars per part |
| Controls | Groove/Kit, Hats/Rides, Level, Tempo; kick and snare pads |
| Outputs | Amp out 1/4 in TS; Mixer L/R impedance-balanced 1/4 in TRS (+19 dBu max); JamSync 1/8 in TRS |
| Inputs | Guitar 1/4 in TS (1 MOhm, +8 dBu max); FS3X 1/4 in TRS |
| Performance | 24-bit, 44.1 kHz, signal to noise 108 dB A-weighted |
| Power | 9 VDC external adapter, 500 mA (PS0913DC-04) |
| Dimensions | 133.4 x 76.2 x 62.2 mm (5.25 x 3 x 2.45 in) |
| Weight | 0.52 kg (1.14 lb) |
| Included | SDrum, PS0913DC 9V DC power adapter |
