Crestron UC-MM30-R Tabletop Conference Device for Crestron Home OS
The UC-MM30-R pairs a business-grade speakerphone with a Crestron Home interface on one desk device, which suits a home office where the same unit should take the call and run the room. Four omnidirectional MEMS microphones cover 360 degrees out to roughly 10 ft, with acoustic echo cancellation, automatic gain control, and dynamic noise reduction to IEEE 1329 Type 1 full duplex, and a 7 W full-range speaker handles playback from 100 Hz to 20 kHz.
The 7 in. capacitive screen runs Crestron Home OS at 1200 x 800. Four capacitive mute buttons with bi-color LEDs ring the unit and a light bar repeats the state in green or red across the room. A PIR occupancy sensor covers about 10 ft at 45 degrees in front of the screen. It takes PoE+ with an injector and cables included, plus dual-band 802.11ac Wi-Fi and a USB 2.0 device port.
| Touch Screen | 7 in. (178 mm) diagonal capacitive multi-touch LCD, 1200 x 800 pixels, Crestron Home OS |
|---|---|
| Microphones | (4) Built-in omnidirectional digital MEMS microphones, 360 degree pickup, 10 ft (3 m) typical range |
| Speaker | Full range, 7 W rated, 83 dBA at 1 m, 100 Hz - 20 kHz |
| Audio Processing | AEC, automatic gain control, dynamic noise reduction, full duplex IEEE 1329 Type 1 |
| Occupancy Sensor | Approx. 10 ft (3 m) PIR range, 45 degree horizontal coverage |
| Network | RJ-45 100BASE-TX/1000BASE-T with PoE+ powered device, dual band 802.11a/b/g/n/ac Wi-Fi |
| Connectors | Micro-USB Type B device port, Kensington security slot |
| Dimensions | 3.02 in. H x 7.17 in. W x 9.61 in. D (77 x 182 x 244 mm), 2.1 lb (0.96 kg) |
