Crestron TS-770-GV 7 in. Tabletop Touch Screen, Government Version
The TS-770-GV is the government build of the 7 in. TS-770 tabletop touch screen. Crestron removes the microphone, the Bluetooth communications beacon, and Wi-Fi network connectivity, so the panel can go into spaces where an open radio or an open microphone is not permitted. Everything else about the interface is unchanged: the same 1280 x 800 capacitive display, the same Smart Graphics and HTML5 projects, and the same five-button collapsible tool bar.
Because the radios are gone, the panel is wired only. A single Ethernet run carries control, PoE+ power, and H.265 or H.264 streaming video from an IP camera, a DM-TXRX-100-STR encoder, or a DigitalMedia switcher. Built-in speakers handle touch feedback and program audio, a USB 2.0 Type-A host port takes supported Crestron accessories, and the plastic housing is offered in black smooth or white smooth.
| Display | 7 in. (178 mm) TFT active matrix color LCD |
|---|---|
| Resolution | 1280 x 800 pixels, 16:10 WXGA |
| Brightness | 350 nits (cd/m2), 850:1 contrast |
| Touch Screen | Projected capacitive, 5-point multitouch capable |
| Omitted for Security | No microphone, no Bluetooth beacon, no Wi-Fi |
| Video | H.265, H.264 (MPEG-4 part 10 AVC), MJPEG, up to 1920x1080 at 30 fps |
| Network | 100 Mbps Ethernet with PoE+ PD, IEEE 802.1X |
| Memory | 2 GB LPDDR3 RAM, 16 GB eMMC pSLC storage |
| Dimensions | 4.02 in. H x 6.87 in. W x 4.37 in. D (102 x 175 x 111 mm) |
